Machine feet type M-3A with fixing
PRODUCT INDEX: 3-1008
Brand: ABAKOSTEEL
M-3A z mocowaniem
- Table of sizes
- Technical drawing
Product index Material The diameter of the base H The diameter of the pin M The height of the pin A Dimensions of the MxA pin Dimensions of the MxA2 nut Product price 3-1008-2-106-16/160-16/55-5 A2 106 16x160 16x55 16x160 16x55 Ask 3-1008-2-106-16/160-16/85-5 A2 106 16x160 16x85 16x160 16x85 Ask 3-1008-2-106-16/210-16/55-5 A2 106 16x210 16x55 16x210 16x55 Ask 3-1008-2-106-16/210-16/85-5 A2 106 16x210 16x85 16x210 16x85 Ask 3-1008-2-106-20/160-20/55-5 A2 106 20x160 20x55 20x160 20x55 Ask 3-1008-2-106-20/160-20/85-5 A2 106 20x160 20x85 20x160 20x85 Ask 3-1008-2-106-20/210-20/55-5 A2 106 20x210 20x55 20x210 20x55 Ask 3-1008-2-106-20/210-20/85-5 A2 106 20x210 20x85 20x210 20x85 Ask 3-1008-2-106-24/160-24/55-5 A2 106 24x160 24x55 24x160 24x55 Ask 3-1008-2-106-24/160-24/85-5 A2 106 24x160 24x85 24x160 24x85 Ask 3-1008-2-106-24/210-24/55-5 A2 106 24x210 24x55 24x210 24x55 Ask 3-1008-2-106-24/210-24/85-5 A2 106 24x210 24x85 24x210 24x85 Ask 3-1008-2-106-30/160-30/55-5 A2 106 30x160 30x55 30x160 30x55 Ask 3-1008-2-106-30/160-30/85-5 A2 106 30x160 30x85 30x160 30x85 Ask 3-1008-2-106-30/210-30/55-5 A2 106 30x210 30x55 30x210 30x55 Ask 3-1008-2-106-30/210-30/85-5 A2 106 30x210 30x85 30x210 30x85 Ask 3-1008-2-106-36/160-36/55-5 A2 106 36x160 36x55 36x160 36x55 Ask 3-1008-2-106-36/160-36/85-5 A2 106 36x160 36x85 36x160 36x85 Ask 3-1008-2-106-36/210-36/55-5 A2 106 36x210 36x55 36x210 36x55 Ask 3-1008-2-106-36/210-36/85-5 A2 106 36x210 36x85 36x210 36x85 Ask 3-1008-2-76-16/160-16/55-5 A2 76 16x160 16x55 16x160 16x55 Ask 3-1008-2-76-16/160-16/85-5 A2 76 16x160 16x85 16x160 16x85 Ask 3-1008-2-76-16/210-16/55-5 A2 76 16x210 16x55 16x210 16x55 Ask 3-1008-2-76-16/210-16/85-5 A2 76 16x210 16x85 16x210 16x85 Ask 3-1008-2-76-20/160-20/55-5 A2 76 20x160 20x55 20x160 20x55 Ask 3-1008-2-76-20/160-20/85-5 A2 76 20x160 20x85 20x160 20x85 Ask 3-1008-2-76-20/210-20/55-5 A2 76 20x210 20x55 20x210 20x55 Ask 3-1008-2-76-20/210-20/85-5 A2 76 20x210 20x85 20x210 20x85 Ask 3-1008-2-76-24/160-24/55-5 A2 76 24x160 24x55 24x160 24x55 Ask 3-1008-2-76-24/160-24/85-5 A2 76 24x160 24x85 24x160 24x85 Ask 3-1008-2-76-24/210-24/55-5 A2 76 24x210 24x55 24x210 24x55 Ask 3-1008-2-76-24/210-24/85-5 A2 76 24x210 24x85 24x210 24x85 Ask 3-1008-2-76-30/160-30/55-5 A2 76 30x160 30x55 30x160 30x55 Ask 3-1008-2-76-30/160-30/85-5 A2 76 30x160 30x85 30x160 30x85 Ask 3-1008-2-76-30/210-30/55-5 A2 76 30x210 30x55 30x210 30x55 Ask 3-1008-2-76-30/210-30/85-5 A2 76 30x210 30x85 30x210 30x85 Ask 3-1008-2-76-36/160-36/55-5 A2 76 36x160 36x55 36x160 36x55 Ask 3-1008-2-76-36/160-36/85-5 A2 76 36x160 36x85 36x160 36x85 Ask 3-1008-2-76-36/210-36/55-5 A2 76 36x210 36x55 36x210 36x55 Ask 3-1008-2-76-36/210-36/85-5 A2 76 36x210 36x85 36x210 36x85 Ask 3-1008-2-77-16/160-16/55-5 A2 77 16x160 16x55 16x160 16x55 Ask 3-1008-2-77-16/160-16/85-5 A2 77 16x160 16x85 16x160 16x85 Ask 3-1008-2-77-16/210-16/55-5 A2 77 16x210 16x55 16x210 16x55 Ask 3-1008-2-77-16/210-16/85-5 A2 77 16x210 16x85 16x210 16x85 Ask 3-1008-2-77-20/160-20/55-5 A2 77 20x160 20x55 20x160 20x55 Ask 3-1008-2-77-20/160-20/85-5 A2 77 20x160 20x85 20x160 20x85 Ask 3-1008-2-77-20/210-20/55-5 A2 77 20x210 20x55 20x210 20x55 Ask 3-1008-2-77-20/210-20/85-5 A2 77 20x210 20x85 20x210 20x85 Ask 3-1008-2-77-24/160-24/55-5 A2 77 24x160 24x55 24x160 24x55 Ask 3-1008-2-77-24/160-24/85-5 A2 77 24x160 24x85 24x160 24x85 Ask 3-1008-2-77-24/210-24/55-5 A2 77 24x210 24x55 24x210 24x55 Ask 3-1008-2-77-24/210-24/85-5 A2 77 24x210 24x85 24x210 24x85 Ask 3-1008-2-77-30/160-30/55-5 A2 77 30x160 30x55 30x160 30x55 Ask 3-1008-2-77-30/160-30/85-5 A2 77 30x160 30x85 30x160 30x85 Ask 3-1008-2-77-30/210-30/55-5 A2 77 30x210 30x55 30x210 30x55 Ask 3-1008-2-77-30/210-30/85-5 A2 77 30x210 30x85 30x210 30x85 Ask 3-1008-2-77-36/160-36/55-5 A2 77 36x160 36x55 36x160 36x55 Ask 3-1008-2-77-36/160-36/85-5 A2 77 36x160 36x85 36x160 36x85 Ask 3-1008-2-77-36/210-36/55-5 A2 77 36x210 36x55 36x210 36x55 Ask 3-1008-2-77-36/210-36/85-5 A2 77 36x210 36x85 36x210 36x85 Ask Product index Material The diameter of the base H The diameter of the pin M The height of the pin A Dimensions of the MxA pin Dimensions of the MxA2 nut Product price
